Foldable Support Bar 750mm with White Steel Column

The 750 mm foldable support bar with support column, model GW11 09 03 00 by Genwec, is designed to enhance safety and accessibility in public or private bathrooms. Made from carbon steel with a white epoxy finish, this bar offers maximum robustness and a durable design, ideal for high-traffic areas and frequent use.

The foldable design with vertical swivel allows for space optimisation when not in use, while the built-in progressive brake system ensures smooth and controlled movement when folding the bar, preventing sudden movements that could compromise user safety. The bar measures 750 mm in length and is constructed from a carbon steel tube with a 32 mm diameter and 1.5 mm thickness, providing solid and secure support for users.

The floor support column, with dimensions of 50 x 50 mm and a thickness of 1.5 mm, adds an extra layer of stability to the assembly, ensuring the bar remains firmly in place, even under intensive use. This column, combined with the 3 mm thick carbon steel brackets, ensures solid anchorage through complete TIG welding without filler, reinforcing the durability and robustness of the foldable bar.

The design of the bar includes an integrated toilet paper holder in the intermediate crossbar, optimising the product's functionality by combining support and accessibility in a single device.

The white epoxy finish not only enhances the product's appearance, giving it a modern and clean look, but also provides excellent corrosion protection, making it suitable for humid environments like bathrooms. Additionally, the bar is ADA compliant (Americans with Disabilities Act), ensuring it meets accessibility standards, improving safety and comfort for people with reduced mobility.

The bar is anchored to the floor using 4 nylon plugs of 10x60 mm and stainless steel screws of 8x70 mm with a hexagonal head, ensuring firm and secure fixation. Once installed, the bar can support a maximum static and dynamic force of 120 kg, making it a reliable option for any environment.

Technical Specifications:

• Bar material: Carbon steel, Ø32 mm and 1.5 mm thickness
• Support column: Carbon steel of 50 x 50 mm and 1.5 mm thickness
• Supports and hinge: 3 mm thick carbon steel
• Progressive brake system: Controlled folding
• Toilet paper holder: Integrated
• Finish: White epoxy, corrosion-resistant
• Compliance: ADA standards
• Floor fixing: 4 nylon plugs of 10x60 mm and screws of 8x70 mm
• Total dimensions: 750 x 850 x 240 mm
• Maximum supported force: 120 kg (static and dynamic)

This foldable support bar is ideal for accessible bathrooms, hospitals, rehabilitation centres or any space that requires a strong and durable support solution. Its anti-vandalism design, combined with its progressive brake system and floor support column, ensures user safety and stability, providing a comfortable and reliable user experience.
